HannStar HSD097PXN1-B00 LCD

Specification

Model P/N:HSD097PXN1-B00
Brand:HannStar
Diagonal Size:9.7"
Resolution:1024(RGB)×768, XGA 132PPI
Brightness:350 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:80/80/70/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:196.608(W)×147.456(H) mm
Bezel Opening:199.8(W)×150.7(H) mm
Response Time:20 (Typ.)(Tr+Td)
Outline Size:210.32(W)×164.37(H) ×5(D) mm
Surface:Hard coating
Best View on:6 o'clock
Display Colors:262K 50% NTSC
Lamp Type:WLED , 10K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:190g (Typ.)
Application:Pad & Tablet
Signal Interface:LVDS (1 ch, 6-bit) , 30 pins Connector
Input Voltage:3.3V (Typ.)
