HannStar HSD097PXN1-A00-0220 LCD

Specification

Model P/N:HSD097PXN1-A00-0220
Brand:HannStar
Diagonal Size:9.7"
Resolution:1024(RGB)×768, XGA 132PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:196.608(W)×147.456(H) mm
Bezel Opening:-
Outline Dim:204.908(H)×156.756(V) ×1.23(D) mm
Treatment:Antiglare
Luminance:0 cd/m²
View Direction:3 o'clock
Response Time:20 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K/16.7M 50% NTSC
Light Source:No B/L
Weight:78.0g (Typ.)
Designed For:Pad & Tablet
Frame Rate:60Hz
Touch Panel:Without
Power Supply:3.3/8.9/19.0/-10V (Typ.)(VDD/AVDD/VGH/VGL)
Plate Thickness:0.40+0.40 mm
Transmittance:5.2% (Typ.)(with Polarizer)
