HannStar HSD097BXN1-A10 LCD

Specification

Model P/N:HSD097BXN1-A10
Brand:HannStar
Diagonal Size:9.7"
Resolution:1024(RGB)×768, XGA 132PPI
Brightness:0 cd/m²
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:80/70/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:196.608(W)×147.456(H) mm
Bezel Opening:-
Response Time:6/14 (Typ.)(Tr/Td)
Outline Size:204.908(W)×156.756(H) ×0.8(D) mm
Surface:Without Polarizer
Best View on:9 o'clock
Display Colors:16.7M 52% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Pad & Tablet ，Digital Photo Frame
Driver IC:COG Suggest HX8282-A06DPD300-A+HX8695-B02BPD250-A, LI6150H2-9G+ILI5801-9G
Glass Depth:0.40+0.40 mm
Transmissivity:12.1% (Typ.)(without Polarizer)
