HannStar HSD096MS11-B00 LCD

Specification

Model P/N:HSD096MS11-B00
Brand:HannStar
Diagonal Size:9.6"
Resolution:800(RGB)×600, SVGA 104PPI
Contrast Ratio:450 : 1 (Typ.) (TM)
Viewing Angle:70/70/45/50 (Typ.)(CR≥10)
Color Depth:262K
Backlight:2 pcs CCFL , 40K hours , No Driver
Signal Type:LVDS (1 ch, 6-bit) , Connector 20 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:194.4(W)×145.8(H) mm
Bezel Opening:197.4(W)×148.8(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:350 cd/m² (Typ.)
Response:16 (Typ.)(Tr+Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:350g (Typ.)
Used for:Digital Photo Frame ，Portable DVD Player
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):224×169.2×9.3 (H×V×D)
