HannStar HSD090ICW1-A00 LCD

Specification

Model P/N:HSD090ICW1-A00
Brand:HannStar
Diagonal Size:9.0"
Resolution:640(RGB)×234 76PPI
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/70/65/65 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:197.76(W)×111.735(H) mm
Bezel Opening:201.0(W)×114.8(H) mm
Outline Dim:210.7(H)×126.4(V) ×4.25(D) mm
Treatment:-
Luminance:250 cd/m² (Typ.)
View Direction:6 o'clock
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:45% NTSC
Light Source:WLED [3S8P] , 30K hours , W/O Driver
Weight:273g (Typ.)
Designed For:Digital Photo Frame ，Portable DVD Player
Frame Rate:-
Touch Panel:Without
Interface Type:TFT Specific Analog RGB , 26 pins FPC
Power Supply:3.3/5/15/-10V (Typ.)(DVDD/AVDD/VGH/VGL)
