HannStar HSD070BFW1-A00 LCD

Specification

Model P/N:HSD070BFW1-A00
Brand:HannStar
Diagonal Size:7.0"
Resolution:1024(RGB)×600, WSVGA 169PPI
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:80/80/80/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:153.6(W)×90(H) mm
Bezel Opening:-
Outline Dim:161.45(H)×98.72(V) ×1(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:12 o'clock
Response Time:4/12 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K 50% NTSC
Light Source:No B/L
Designed For:Netbook PC ，Digital Photo Frame ，Portable DVD Player
Frame Rate:60Hz
Touch Panel:Without
Interface Type:LVDS
Form Style:-
Plate Thickness:0.50+0.50 mm
Transmittance:13.69% (Typ.)(without Polarizer)
D-IC Detail:COG Suggest NT51008 + NT52002
