HannStar HSD053B8W1-C00 LCD

Specification

Model P/N:HSD053B8W1-C00 1
Brand:HannStar
Diagonal Size:5.3"
Resolution:480(RGB)×854, FWVGA 186PPI
Brightness:0 cd/m²
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:70/70/70/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:65.52(W)×116.571(H) mm
Bezel Opening:-
Response Time:4/12 (Typ.)(Tr/Td)
Outline Size:68.61(W)×124.68(H) ×0.5(D) mm
Surface:Without Polarizer
Best View on:12 o'clock
Display Colors:16.7M 60% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Mobile Phone
Driver IC:COGSuggest HX8379-A, NT35510, NT35510S, NT35512, OTM8009A, OTM8018B, RM68171, RM68180
Glass Depth:0.25+0.25 mm
Transmissivity:4.74% (Typ.)(with Polarizer)
