HannStar HSD050I9W1-A00-R00 LCD

Specification

Model P/N:HSD050I9W1-A00-R00
Brand:HannStar
Diagonal Size:5.0"
Resolution:480(RGB)×272, WQVGA 109PPI
Contrast Ratio:800 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 45% NTSC
Backlight:7S2P WLED , 10K hours , No Driver
Signal Type:Parallel RGB (1 ch, 8-bit) , FPC 45 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:110.88(W)×62.832(H) mm
Bezel Opening:115.8(W)×66.7(H) mm
Treatment:Antiglare, Hard coating (3H)
Luminance:400 cd/m² (Typ.)
Response:15/17 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:74.0g (Typ.)
Used for:Automotive Display
Refresh Rate:60Hz
Touchscreen:4-wire Resistive Touch
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -40 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.9G (28.4 m/s²)
Outline (mm):120.7×75.8×5.45 (H×V×D)
