HannStar HSD050HDW4-A30 LCD

Specification

Model P/N:HSD050HDW4-A30
Brand:HannStar
Diagonal Size:5.0"
Resolution:800(RGB)×480, WVGA 188PPI
Brightness:-
Contrast Ratio:15:1 (Typ.) (TM) 15:1 (Typ.) (RF)
Viewing Angle:60/60/30/30 (Typ.)(CR≥2)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:108(W)×64.8(H) mm
Bezel Opening:-
Response Time:6 (Typ.)(Tr+Td)
Outline Size:114(W)×72.3(H) ×0.94(D) mm
Surface:-
Best View on:-
Display Colors:16.2M 30% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Industrial
Driver IC:COG Suggest HX8264D, OTA7001, ILI6126S-1, ILI6126E, ILI6123H-9G, EK9716B, NT39416UT, ST5625CA
Glass Depth:0.40+0.40 mm
Transmissivity:1.7% (Typ.)(with Polarizer)
