HannStar HSD045FMW1-C11 LCD

Specification

Model P/N:HSD045FMW1-C11
Brand:HannStar
Diagonal Size:4.5"
Resolution:540(RGB)×960, qHD 247PPI
Contrast Ratio:700 : 1 (Typ.) (TM)
Viewing Angle:70/70/60/70 (Typ.)(CR≥10)
Color Depth:16.7M 70% NTSC
Backlight:No B/L
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:55.485(W)×98.64(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Response:4/12 (Typ.)(Tr/Td) ms
Good View at:6 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:Without
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):58.485×106.34×0.5 (H×V×D)
Driver IC list:Suggest COG ILI9807, NT35516
Transmissivity:3.3% (Typ.)(with Polarizer)
Glass Thickness:0.25+0.25 mm
