HannStar HSD043F8W2-B00 LCD

Specification

Model P/N:HSD043F8W2-B00
Brand:HannStar
Diagonal Size:4.3"
Resolution:480(RGB)×800, WVGA 217PPI
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:70/70/70/60 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:56.16(W)×93.6(H) mm
Bezel Opening:-
Outline Dim:59.36(H)×101.3(V) ×0.6(D) mm
Treatment:-
Luminance:0 cd/m²
View Direction:12 o'clock
Response Time:4/12 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 62% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.30+0.30 mm
Transmittance:4.61% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest NT35510
