HannStar HSD018B1N9-A00 LCD

Specification

Model P/N:HSD018B1N9-A00 8
Brand:HannStar
Diagonal Size:1.77"
Resolution:128(RGB)×160 115PPI
Brightness:0 cd/m²
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:45/45/45/20 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:28.032(W)×35.04(H) mm
Bezel Opening:-
Response Time:2/6 (Typ.)(Tr/Td)
Outline Size:31.832(W)×41.42(H) ×1(D) mm
Surface:Without Polarizer
Best View on:12 o'clock
Display Colors:262K 60% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Mobile Phone
Driver IC:COG Suggest HX8353-C, HX8353-D, HX8353-E, ILI9163, ILI9163B, ILI9163C, NT39121, NT39121C, NT39121D, S6D02A0, S6D02A1, S6D02A2, SPF5414D, SPFD54124C, ST7715, ST7715R, ST7732, ST7735, ST7735R, ST7735S
Glass Depth:0.50+0.50 mm
Transmissivity:19.1% (Typ.)(without Polarizer)
