AUO H649TAX01.0 LCD

Specification

Model P/N:H649TAX01.0
Brand:AUO
Diagonal Size:6.5"
Resolution:720(RGB)×1560 264PPI
Contrast Ratio:1200 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 70% NTSC
Backlight:No B/L
Signal Type:MIPI
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:69.12(W)×149.76(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Outline(mm):71.12 × 154.76 × 0.3 (H×V×D)
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:AHVA, Normally Black, Transmissive
Mass:-
Used for:Mobile Phone
Refresh Rate:60Hz
Touchscreen:In-Cell Touch
Voltage Supply:1.5/1.8/5.5/-5.5V (Typ.)(VDD/VDDI/AVDD/AVEE)
Max Ratings:Storage Temp.: -55 ~ 110 °C Operating Temp.: -30 ~ 70 °C
Driver IC list:Suggest COG FT8006P, NT36525B, ILI9881H
Transmissivity:3.47% (Typ.)
Glass Thickness:0.15+0.15 mm
