AUO H592DAN01.0 LCD

Specification

Model P/N:H592DAN01.0
Brand:AUO
Diagonal Size:5.9"
Resolution:1080(RGB)×2160 407PPI
Contrast Ratio:1300 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:16.7M 70% NTSC
Backlight:No B/L
Panel Type:LTPS TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:67.392(W)×134.784(H) mm
Bezel Opening:-
Treatment:Without Polarizer
Luminance:0 cd/m²
Outline(mm):68.992 × 139.884 × 0.4 (H×V×D)
Response:35 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:AHVA, Normally Black, Transmissive
Mass:9.85±0.35g
Used for:Mobile Phone
Refresh Rate:-
Touchscreen:Without
Voltage Supply:1.8/5.5/-5.5V (Typ.)(VDDI/AVDD/AVEE)
Max Ratings:Storage Temp.: -55 ~ 110 °C Operating Temp.: -30 ~ 70 °C
Driver IC list:Built-in COG NT35692, OTM911A, ILI7807D, S6D6FA2
Transmissivity:4.7% (Typ.)(with APCF)
Glass Thickness:0.20+0.20 mm
