AUO H570TAX01.0 LCD

Specification

Model P/N:H570TAX01.0
Brand:AUO
Diagonal Size:5.7"
Resolution:720(RGB)×1440 282PPI
Brightness:0 cd/m²
Contrast Ratio:1200:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:64.8(W)×129.6(H) mm
Bezel Opening:-
Response Time:30 (Typ.)(Tr+Td)
Outline Size:66.8(W)×135.5(H) ×0.3(D) mm
Surface:Without Polarizer
Best View on:Symmetry
Display Colors:16.7M 72% NTSC
Lamp Type:No B/L
Frequency:60Hz
Touch Screen:In-Cell Touch
Panel Weight:-
Application:Mobile Phone
Signal Interface:MIPI
Driver IC:COGBuilt-in FT8006M. FT8006_ FT8006U_NT36525_TD4130_HX83102B_ILI9881F Optional
Glass Depth:0.15+0.15 mm
Transmissivity:5.08% (Typ.)(with Polarizer)
