AUO H564DAN01.0 LCD

Specification

Model P/N:H564DAN01.0
Brand:AUO
Diagonal Size:5.6"
Resolution:1080(RGB)×2160 427PPI
Contrast Ratio:1400:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:LTPS TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:64.152(W)×128.304(H) mm
Bezel Opening:-
Outline Dim:65.75(H)×133.1(V) ×0.3(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:15/15 (Typ.)(Tr/Td), 40 (Typ.)(G to G)
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:TBD
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Interface Type:MIPI
Power Supply:1.8/5.5/5.5V (Typ.)(VDDI/AVDD/AVEE)
Plate Thickness:0.15+0.15 mm
Transmittance:4.32% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest OTM1911A, NT35692, HX8399C, ILI7807D, S6D6FA2
