AUO H546DAN08.0 LCD

Specification

Model P/N:H546DAN08.0
Brand:AUO
Diagonal Size:5.5"
Resolution:1080(RGB)×1920, FHD 403PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:68.04(W)×120.96(H) mm
Bezel Opening:-
Outline Dim:70.44(H)×127.16(V) ×0.3(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:35 (Typ.)(Tr+Td)
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.7M 72% NTSC
Light Source:No B/L
Weight:7.00g (Typ.)
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Power Supply:1.8/3.0/15/-12V (Typ.)(VDD/VDDI/VGH/VGL)
Plate Thickness:0.15+0.15 mm
Transmittance:3.7% (Typ.)(with APCF)
D-IC Detail:COG Suggest NT35532, HX8398A, ILI9885, OTM1903A, R61322
