AUO H426TAN02.0 LCD

Specification

Model P/N:H426TAN02.0
Brand:AUO
Diagonal Size:4.3"
Resolution:720(RGB)×1280, WXGA 344PPI
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:LTPS TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:53.136(W)×94.464(H) mm
Bezel Opening:-
Outline Dim:55.14(H)×101.09(V) ×0.546(D) mm
Treatment:-
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:20/20 (Typ.)(Tr/Td)
Operating Mode:AHVA, Normally Black, Transmissive
Support Color:16.7M
Light Source:No B/L
Weight:5.50g
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Power Supply:1.8/3.3V (Typ.)(VDDI/VCI)
Plate Thickness:0.15+0.15 mm
Transmittance:5.11% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest NT35590
