AUO H320QW01 V0 LCD

Specification

Model P/N:H320QW01 V0
Brand:AUO
Diagonal Size:3.2"
Resolution:240(RGB)×400, WQVGA 145PPI
Brightness:0 cd/m²
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:40/40/50/15 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:41.76(W)×69.6(H) mm
Bezel Opening:-
Response Time:15/20 (Typ.)(Tr/Td)
Outline Size:44.9(W)×76.74(H) ×0.6(D) mm
Surface:Without Polarizer
Best View on:12 o'clock
Display Colors:262K 69% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:TBD
Application:Mobile Phone
Input Voltage:1.8/2.8V (Typ.)(IOVCC/VCI)
Driver IC:COGBuilt-in ILI9327
Glass Depth:0.30+0.30 mm
Transmissivity:11.7% (Typ.)(without Polarizer)
