AUO H241QN01 V3 LCD

Specification

Model P/N:H241QN01 V3 6
Brand:AUO
Diagonal Size:2.4"
Resolution:240(RGB)×320, QVGA 166PPI
Brightness:0 cd/m²
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:45/45/50/20 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:36.72(W)×48.96(H) mm
Bezel Opening:-
Response Time:15/20 (Typ.)(Tr/Td)
Outline Size:40.58(W)×56.96(H) ×1(D) mm
Surface:Without Polarizer
Best View on:12 o'clock
Display Colors:262K 55% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:4.50g
Application:Mobile Phone
Signal Interface:CPU
Driver IC:COG Suggest NT39116, SPFD5408B, ILI9325
Glass Depth:0.50+0.50 mm
Transmissivity:15.5% (Typ.)(without Polarizer)
