AUO H210HN00 V0 LCD

Specification

Model P/N:H210HN00 V0
Brand:AUO
Diagonal Size:2.1"
Resolution:176(RGB)×220, QCIF+ 134PPI
Brightness:0 cd/m²
Contrast Ratio:200:1 (Typ.) (TM)
Viewing Angle:40/40/60/15 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:33.264(W)×41.58(H) mm
Bezel Opening:-
Response Time:12/18 (Typ.)(Tr/Td)
Outline Size:36.67(W)×49.65(H) ×0.88(D) mm
Surface:Antiglare
Best View on:12 o'clock
Display Colors:262K 44% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:3.00±0.30g
Application:Mobile Phone
Input Voltage:1.95/3.3/3.3V (Max.)(VDD/VDD3/VCI)
Driver IC:COGSuggest S6D0128
Glass Depth:0.30+0.30 mm
Transmissivity:6.8% (Typ.)(with Polarizer)
