AUO H200HN04 V0 LCD

Specification

Model P/N:H200HN04 V0
Brand:AUO
Diagonal Size:2.0"
Resolution:176(RGB)×220, QCIF+ 141PPI
Brightness:0 cd/m²
Contrast Ratio:350:1 (Typ.) (TM)
Viewing Angle:40/40/60/15 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Full Cell
Pixel Format:RGB Vertical Stripe
Active Area:31.68(W)×39.6(H) mm
Bezel Opening:-
Response Time:15/20 (Typ.)(Tr/Td)
Outline Size:35.08(W)×47.1(H) ×0.6(D) mm
Surface:Without Polarizer
Best View on:12 o'clock
Display Colors:262K 60% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:TBD
Application:Mobile Phone
Signal Interface:CPU/RGB/SPI
Driver IC:COG Suggest R61503
Glass Depth:0.30+0.30 mm
Transmissivity:15.2% (Typ.)(without Polarizer)
