H154QN01 V2 AUO LCD panel replacement for MP3 Player,Smart Watch

Brand：AUO
Model：H154QN01 V2
Diagonal Size：1.54 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：240(RGB)×240
Configuration：RGB Vertical Stripe
Active Area：27.72(H)×27.72(V) mm
Outline Dim.：31.82(H)×33.72(V) mm
Luminance：500 cd/m2 (Typ.)
Contrast Ratio：150:1 (Typ.) (TM)
View Direction：-
Response Time：6/20 (Typ.)(Tr/Td)
Viewing Angle：60/35/55/60 (Typ.)(CR≥10)
Operating Mode：ECB， Normally White， Transmissive
Support Color：262K 50%(CIE1931)
Light Source：WLED[5 pcs]， W/O Driver
Weight： 2.40g
Designed For： MP3 Player, Smart Watch,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 12 pinsMIPI (1 data lane)， Connector
Power Supply：1.8/3.0V (Typ.)(VDD3/VCI)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
