AU Optronics H019HT01 LCD

Specification

Model P/N:H019HT01
Brand:AU Optronics
Diagonal Size:1.9"
Resolution:176(RGB)×220, QCIF+ 149PPI
Brightness:145 cd/m² (Typ.)
Contrast Ratio:80:1 (Typ.) (TM) 10:1 (Typ.) (RF)
Viewing Angle:45/45/35/35 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:29.832(W)×37.29(H) mm
Bezel Opening:-
Response Time:15/25 (Typ.)(Tr/Td)
Outline Size:37.5(W)×50.95(H) ×3.38(D) mm
Surface:Hard coating, Antireflection
Best View on:6 o'clock
Display Colors:262K 50% NTSC
Lamp Type:WLED , 10K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:12.0g (Typ.)
Application:Mobile Phone
Signal Interface:Parallel RGB (1 ch, 6-bit) , 40 pins Connector
Input Voltage:2.5/3.6V (Max.)(VDD/VCI)
