BOE GV058QHB-N81-28P0 LCD

Specification

Model P/N:GV058QHB-N81-28P0
Brand:BOE
Diagonal Size:5.8"
Resolution:1440×2560 508PPI
Brightness:0 cd/m²
Contrast Ratio:400:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , FOG
Pixel Format:Rectangle
Active Area:72(W)×128(H) mm
Bezel Opening:-
Response Time:40 (Max.)(Tr+Td)
Outline Size:76(W)×136.45(H) ×0.95(D) mm
Surface:-
Best View on:Symmetry
Display Colors:Grayscale
Lamp Type:No B/L
Frequency:60Hz
Touch Screen:Without
Panel Weight:-
Application:3D Printer
Signal Interface:MIPI (2 ch, 4 data lanes) , 50 pins Connector
Input Voltage:1.8/5/-5.5V (Typ.)(VCC/VSP/VSN)
Driver IC:COG Built-in HX8252A_00*2
Glass Depth:0.40+0.40 mm
Transmissivity:5.1% (Typ.)
