BOE GV055FHM-N42-18P0 LCD

Specification

Model P/N:GV055FHM-N42-18P0
Brand:BOE
Diagonal Size:5.5"
Resolution:1080×1920(RGB), FHD 403PPI
Contrast Ratio:1500:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Horizontal Stripe
Active Area:68.04(W)×120.96(H) mm
Bezel Opening:-
Outline Dim:70.44(H)×128.79(V) ×2(D) mm
Treatment:-
Luminance:900 cd/m² (Typ.)
View Direction:Symmetry
Response Time:25 (Typ.)(Tr+Td)
Operating Mode:ADS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:WLED , W/O Driver
Weight:TBD
Designed For:Outdoor High Brightness ，Handheld & PDA
Frame Rate:60Hz
Touch Panel:Without, I²C
Interface Type:MIPI (4 data lanes) , 40 pins Connector
Power Supply:1.8/5.54/5.54V (Typ.)(VCC/VSP/VSN)
