Giantplus GPM1316D0 LCD

Specification

Model P/N:GPM1316D0 1
Brand:Giantplus
Diagonal Size:4.0"
Resolution:480(RGB)×800, WVGA 235PPI
Contrast Ratio:900:1 (Typ.) (TM)
Viewing Angle:75/75/75/75 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , COG
Pixel Format:RGB Vertical Stripe
Active Area:51.84(W)×86.4(H) mm
Bezel Opening:-
Outline Dim:55.14(H)×93.6(V) ×0.98(D) mm
Treatment:Hard coating (3H)
Luminance:0 cd/m²
View Direction:9 o'clock
Response Time:20/10 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:16.7M 50% NTSC
Light Source:No B/L
Weight:10.6g
Designed For:Mobile Phone
Frame Rate:60Hz
Touch Panel:Without
Power Supply:1.8/3.0V (Typ.)(IOVCC/VCI)
Plate Thickness:0.30+0.30 mm
Transmittance:-
D-IC Detail:COG Built-in HX8369-B
