AUO G150XTK01.2 LCD

Specification

Model P/N:G150XTK01.2
Brand:AUO
Diagonal Size:15.0"
Resolution:1024(RGB)×768, XGA 85PPI
Contrast Ratio:700:1 (Typ.) (TM)
Viewing Angle:80/80/70/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:304.128(W)×228.096(H) mm
Bezel Opening:-
Outline Dim:326.5(H)×253.5(V) ×10(D) mm
Treatment:-
Luminance:390 cd/m² (Typ.)
View Direction:-
Response Time:5.7/2.3 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:262K/16.2M 60% NTSC
Light Source:WLED , 70K hours , With LED Driver
Weight:1.15Kgs (Max.)
Designed For:Industrial
Frame Rate:60Hz
Touch Panel:On-Cell Touch, USB
Interface Type:LVDS (1 ch, 6/8-bit) , 20 pins Connector
Power Supply:3.3V (Typ.)
