AUO G101EVN03.1 LCD

Specification

Model P/N:G101EVN03.1
Brand:AUO
Diagonal Size:10.1"
Resolution:1280(RGB)×800, WXGA 149PPI
Contrast Ratio:1300 : 1 (Typ.) (TM)
Viewing Angle:85/85/85/85 (Typ.)(CR≥10)
Color Depth:262K/16.2M 45% NTSC
Backlight:WLED , 50K hours , No Driver
Signal Type:LVDS (1 ch, 6/8-bit) , 40 pins Connector
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:216.96(W)×135.6(H) mm
Bezel Opening:-
Treatment:Glare (Haze 0%)
Luminance:1000 cd/m² (Typ.)
Outline(mm):227.69 × 148.31 × 7.75 (H×V×D)
Response:25 (Typ.)(Tr+Td) ms
Good View at:Symmetry
Work Mode:MVA, Normally Black, Transmissive
Mass:350g (Max.)
Used for:Industrial ，Outdoor High Brightness
Refresh Rate:60Hz
Touchscreen:Without
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 70 °C Operating Temp.: -20 ~ 70 °C
