AUO G090VTN02.0 LCD

Specification

Model P/N:G090VTN02.0 3
Brand:AUO
Diagonal Size:9.0"
Resolution:800(RGB)×480, WVGA 104PPI
Brightness:300 cd/m² (Typ.)
Contrast Ratio:500:1 (Typ.) (TM)
Viewing Angle:70/70/50/70 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:198(W)×111.696(H) mm
Bezel Opening:201.0(W)×114.7(H) mm
Response Time:10/15 (Typ.)(Tr/Td)
Outline Size:211.1(W)×128.4(H) ×7.1(D) mm
Surface:Antiglare, Hard coating (3H)
Best View on:6 o'clock
Display Colors:16.7M 50% NTSC
Lamp Type:WLED , 20K hours , With LED Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:255g (Typ.)
Application:Industrial
Signal Interface:TTL (1 ch, 8-bit) , 50 pins Connector
Input Voltage:3.3V (Typ.)
