G084SN05 V5 AUO LCD panel replacement for Industrial Application

Panel Brand：AUO
Panel Model：G084SN05 V5
Panel Size：8.4 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：800(RGB)×600 , SVGA
Pixel Format：RGB Vertical Stripe
Display Area：170.4(W)×127.8(H) mm
Bezel Opening：173.6(W)×130.8(H) mm
Outline Size：203(W)×142.5(H)×12.7(D) mm
Surface：-
Brightness：350 cd/m2 (Typ.)
Contrast Ratio：500:1 (Typ.) (TM)
Viewing Angle：60/60/60/40 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：12 o'clock
Response Time：10/25 (Typ.)(Tr/Td)
Display Colors：262K
Lamp Type：2 pcsCCFL, 50K hours, Without Driver
Frequency：60Hz
Touch Screen：Without
Panel Weight： 260±10g
Application： Industrial Application,
Signal Interface： Analog RGB + TTL (1 ch, 6-bit), 45 pins, Connector
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
