G084SN03 V3 AUO LCD panel replacement for Industrial Application

Panel Brand：AUO
Panel Model：G084SN03 V3
Panel Size：8.4 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：800(RGB)×600 , SVGA
Pixel Format：RGB Vertical Stripe
Display Area：170.4(W)×127.8(H) mm
Bezel Opening：173.8(W)×131.2(H) mm
Outline Size：203(W)×142.5(H) mm
Surface：Antiglare, Hard coating (3H)
Brightness：250 cd/m2 (Typ.)
Contrast Ratio：600:1 (Typ.) (TM)
Viewing Angle：80/80/80/60 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：-
Response Time：20/10 (Typ.)(Tr/Td)
Display Colors：262K/16.2M 45%(CIE1931)
Lamp Type：3 stringsWLED, 30K hours, With LED Driver
Frequency：60Hz
Touch Screen：Without
Panel Weight： TBD
Application Industrial Application,Signal Interface： LVDS (1 ch, 6/8-bit), 20 pins, Connector
Input Voltage：3.3V (Typ.)
Environment：Operating Temp.: -20 ~ 70 °C ;Storage Temp.: -20 ~ 70 °C
