CMO F07020-01D LCD

Specification

Model P/N:F07020-01D
Brand:CMO
Diagonal Size:7.0"
Resolution:480(RGB)×234 76PPI
Contrast Ratio:250:1 (Typ.) (TM)
Viewing Angle:45/45/15/35 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Empty Cell)
Pixel Format:RGB Vertical Stripe
Active Area:154.08(W)×86.58(H) mm
Bezel Opening:-
Outline Dim:162.17(H)×94.5(V) ×1(D) mm
Treatment:-
Luminance:0 cd/m²
View Direction:6 o'clock
Response Time:15/35 (Typ.)(Tr/Td)
Operating Mode:TN, Normally White, Transmissive
Support Color:Full color 52% NTSC
Light Source:No B/L
Weight:-
Designed For:Digital Photo Frame ，Portable DVD Player
Frame Rate:-
Touch Panel:Without
Interface Type:TFT Specific Analog RGB
Plate Thickness:0.50+0.50 mm
Transmittance:8.6% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest HX8226 + HX8660B
