Innolux F060A09-6T2 LCD

Specification

Model P/N:F060A09-6T2
Brand:Innolux
Diagonal Size:6.0"
Resolution:720(RGB)×1280, WXGA 245PPI
Brightness:0 cd/m²
Contrast Ratio:1000:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:74.52(W)×132.48(H) mm
Bezel Opening:-
Response Time:14/11 (Typ.)(Tr/Td)
Outline Size:77.32(W)×140.13(H) ×0.8(D) mm
Surface:Without Polarizer
Best View on:Symmetry
Display Colors:16.7M 70% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:On-Cell Touch
Panel Weight:-
Application:Mobile Phone
Driver IC:COGSuggest HX8394-A01, NT35521, OTM1283A + OTM1288A
Glass Depth:0.40+0.40 mm
Transmissivity:4.0% (Typ.)(with Polarizer)
