Innolux F060A09-603 LCD

Specification

Model P/N:F060A09-603 3
Brand:Innolux
Diagonal Size:6.0"
Resolution:720(RGB)×1280, WXGA 245PPI
Contrast Ratio:900:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:74.52(W)×132.48(H) mm
Bezel Opening:-
Outline Dim:77.32(H)×140.13(V) ×0.4(D) mm
Treatment:Without Polarizer
Luminance:0 cd/m²
View Direction:Symmetry
Response Time:14/11 (Typ.)(Tr/Td)
Operating Mode:IPS, Normally Black, Transmissive
Support Color:16.7M 70% NTSC
Light Source:No B/L
Weight:-
Designed For:Mobile Phone
Frame Rate:-
Touch Panel:Without
Plate Thickness:0.20+0.20 mm
Transmittance:3.7% (Typ.)(with Polarizer)
D-IC Detail:COG Suggest HX8394-A01, HX8394-D, ILI9881, NT35521S, OTM1283A, OTM1284A, OTM1288A
