Innolux F035A05-601 LCD

Specification

Model P/N:F035A05-601
Brand:Innolux
Diagonal Size:3.5"
Resolution:320(RGB)×240, QVGA 115PPI
Brightness:0 cd/m²
Contrast Ratio:800:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:70.08(W)×52.56(H) mm
Bezel Opening:-
Response Time:25 (Typ.)(Tr+Td)
Outline Size:75.1(W)×60.26(H) ×0.8(D) mm
Surface:Without Polarizer
Best View on:Symmetry
Display Colors:16.7M 60% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:TBD
Application:Handheld & PDA ，Automotive Display ，VOIP Phone
Driver IC:COGSuggest ST7272A
Glass Depth:0.40+0.40 mm
Transmissivity:6.35% (Typ.)(with Polarizer)
