CMO F03004-02U LCD

Specification

Model P/N:F03004-02U
Brand:CMO
Diagonal Size:3.0"
Resolution:240(RGB)×400, WQVGA 156PPI
Brightness:0 cd/m²
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:45/45/35/15 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, CELL , Q-CUT (Full Cell)
Pixel Format:RGB Vertical Stripe
Active Area:38.88(W)×64.8(H) mm
Bezel Opening:-
Response Time:10/20 (Typ.)(Tr/Td)
Outline Size:42.88(W)×73.1(H) ×1(D) mm
Surface:Without Polarizer
Best View on:12 o'clock
Display Colors:262K 61% NTSC
Lamp Type:No B/L
Frequency:-
Touch Screen:Without
Panel Weight:-
Application:Mobile Phone ，MP3 PMP
Driver IC:COG Suggest HX8352-A, HX8352-B
Glass Depth:0.50+0.50 mm
Transmissivity:6.15% (Typ.)(with Polarizer)
