ET0320A5DM9 EDT LCD panel replacement

Brand：EDT
Model：ET0320A5DM9
Diagonal Size：3.2 inch
Type：a-Si TFT-LCD， LCM
Pixel Format：240(RGB)×320[QVGA]
Configuration：RGB Vertical Stripe
Active Area：48.6(H)×64.8(V) mm
Outline Dim.：55.14(H)×76.8(V)×6(D) mm
Bezel Area：50.6(H)×66.8(V) mm
Treatment：-
Luminance：350 cd/m2 (Typ.)
Contrast Ratio：450:1 (Typ.) (TM)
View Direction：-
Response Time：5/15 (Typ.)(Tr/Td)
Viewing Angle：63/70/65/72 (Typ.)(CR≥10)
Operating Mode：TN， Normally White， Transmissive
Support Color：262K 59%(CIE1931)
Light Source：WLED[6S1P]， 40K hours， W/O Driver
Weight： –
Designed For： Handheld & PDA, Mobile Phone,
Frame Rate：60Hz
Touch Panel：Without
Interface Type： 41 pins8/9/16/18-bit 8080 parallel， FPC
Power Supply：3.3/3.3V (Typ.)(IOVCC/VCC)
Environment： Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C
