E Ink ES108FC1 LCD

Specification

Model P/N:ES108FC1
Brand:E Ink
Diagonal Size:10.8"
Resolution:1920×1080, FHD 204PPI
Contrast Ratio:16:1 (Typ.) (RF)
Viewing Angle:-
Color Depth:Grayscale
Backlight:No B/L
Signal Type:Parallel Data (2ch, 8-bit) , FPC 50 pins
Panel Type:EPD, EPD
Pixel Format:Rectangle
Active Area:239.04(W)×134.46(H) mm
Bezel Opening:-
Treatment:-
Luminance:-
Response:-
Good View at:-
Work Mode:Reflective
Mass:TBD
Used for:E-Book Reader
Refresh Rate:-
Touchscreen:Without
Voltage Supply:1.8/3.3/28/-20V (Typ.)(VDD2/VDD/VGH/VGL)
Max Ratings:Storage Temp.: -25 ~ 70 °C Operating Temp.: 0 ~ 50 °C
Outline (mm):247.04×153.76×0.54 (H×V×D)
