EJ070NA-01J Innolux LCD panel replacement for MP4 PMP, Netbook PC

Panel Brand：Chimei Innolux
Panel Model：EJ070NA-01J4 Compatible
Panel Size：7.0 inch
Panel Type：a-Si TFT-LCD, LCM
Resolution：1024(RGB)×600 , WSVGA
Pixel Format：RGB Vertical Stripe
Display Area：153.6(W)×90(H) mm
Bezel Opening：156.14(W)×92.60(H) mm
Outline Size：165.75(W)×105.39(H)×3.7(D) mm
Surface：Glare (Haze 0%), Hard coating
Brightness：250 cd/m2 (Typ.)
Contrast Ratio：700:1 (Typ.) (TM)
Viewing Angle：75/75/70/75 (Typ.)(CR≥10)
Display Mode：TN, Normally White, Transmissive
Best View on：6 o’clock
Response Time：10/15 (Typ.)(Tr/Td)
Display Colors：262K/16.7M 70%(CIE1931)
Lamp Type：3S8PWLED, 20K hours, Without Driver
Frequency： 60Hz
Touch Screen：Without
Shape Style： –
Application： MP4 PMP, Netbook PC,
Signal Interface： LVDS (1 ch, 6/8-bit), 40 pins , FPC
Input Voltage：3.3/11/20/-6.8V (Typ.)(DVDD/AVDD/VGH/VGL)
Environment： Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C
