E1392AM1.A EDO LCD panel replacement

Brand：EDO
Model：E1392AM1.A
Diagonal Size：1.39 inch
Type：AM-OLED, OLED
Pixel Format：400(RGB)×400
Configuration：RGB Vertical Stripe
Active Area：35.4(H)×35.4(V) mm
Outline Dim.：38.6(H)×40.5(V)×0.75(D) mm
Luminance：300 cd/m2 (Typ.)
Contrast Ratio：10000:1 (Typ.) (TM)
View Direction：Symmetry
Response Time：4 (Max.)(Tr+Td)
Viewing Angle：85/85/85/85 (Typ.)(CR≥200)
Operating Mode：-
Support Color：16.7M 100%(CIE1931)
Light Source：self
Weight：TBD
Designed For： Smart Watch,
Frame Rate：-
Touch Panel：Without
Interface Type： 20 pinsMIPI (1 data lane), Connector
Power Supply：1.8/2.8V (Typ.)(IOVCC/VCI)
Environment：Operating Temperature: -20 ~ 60 °C; Storage Temperature: -30 ~ 70 °C
