OPTREX DMF-50262NB-FW LCD

Specification

Model P/N:DMF-50262NB-FW
Brand:OPTREX
Diagonal Size:8.9"
Resolution:640×400 84PPI
Brightness:55 cd/m² (Typ.)
Contrast Ratio:5:1 (Typ.) (TM)
Viewing Angle:-
Panel Type:FSTN-LCD, LCM
Pixel Format:Rectangle
Active Area:191.97(W)×119.97(H) mm
Bezel Opening:200.0(W)×128.0(H) mm
Response Time:150/330 (Typ.)(Tr/Td)
Outline Size:255(W)×147(H) ×7(D) mm
Surface:-
Best View on:6 o'clock
Display Colors:Monochrome
Lamp Type:1 pcs CCFL , 15K hours , Without Driver
Frequency:70Hz
Touch Screen:Without
Panel Weight:310g (Max.)
Application:Industrial
Signal Interface:Parallel Data (1ch, 4-bit) , 15 pins Connector
Input Voltage:5.0V (Typ.)
