DMF-50174ZNB-FW Kyocera LCD panel replacement for Industrial Application

Panel Brand：OPTREX
Panel Model：DMF-50174ZNB-FW
Panel Size：5.7 inch
Panel Type：STN-LCD, LCM
Resolution：320×240 , QVGA
Pixel Format：Rectangle
Display Area：115.17(W)×86.37(H) mm
Bezel Opening：122.0(W)×92.0(H) mm
Outline Size：174(W)×115(H) mm
Surface：-
Brightness：50 cd/m2 (Typ.)
Contrast Ratio：4:1 (Typ.) (TM)
Viewing Angle：-
Display Mode：STN, Transmissive
Best View on：6 o’clock
Response Time：100/360 (Typ.)(Tr/Td)
Display Colors：Monochrome
Lamp Type：1 pcsCCFL, 15K hours, Without Driver
Frequency：70Hz
Touch Screen：Without
Panel Weight： 300g (Max.)
Application： Industrial Application,
Signal Interface： Parallel Data (4-bit), 14 pins, Connector
Input Voltage：5.0V (Typ.)
Environment：Operating Temp.: 0 ~ 50 °C ;Storage Temp.: -20 ~ 60 °C
