Ortustech COM48H4N27ULX LCD

Specification

Model P/N:COM48H4N27ULX 5
Brand:Ortustech
Diagonal Size:4.8"
Resolution:720(RGB)×1280, WXGA 309PPI
Contrast Ratio:700 : 1 (Typ.) (TM) 3:1 (Typ.) (RF)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Color Depth:16.7M 50% NTSC
Backlight:9S1P WLED , 20K hours , No Driver
Signal Type:MIPI (4 data lanes) , Connector 26 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:59.184(W)×105.216(H) mm
Bezel Opening:-
Treatment:Hard coating (2H)
Luminance:300 cd/m² (Typ.)
Response:40/60 (Max.)(Tr/Td) ms
Good View at:Symmetry
Work Mode:VA, Normally Black, Transflective
Mass:25.2g
Used for:Handheld & PDA
Refresh Rate:-
Touchscreen:Without
Voltage Supply:1.9/2.9V (Typ.)(IOVCC/VCC)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C ; Vibration Level: 2.0G (19.6 m/s²)
Outline (mm):63.68×115.51×2.47 (H×V×D)
