Ortustech COM43H4N91UTC LCD

Specification

Model P/N:COM43H4N91UTC
Brand:Ortustech
Diagonal Size:4.3"
Resolution:480(RGB)×800, WVGA 218PPI
Brightness:320 cd/m² (Typ.)
Contrast Ratio:600:1 (Typ.) (TM) 1.5:1 (Typ.) (RF)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:55.8(W)×93(H) mm
Bezel Opening:-
Response Time:40/60 (Max.)(Tr/Td)
Outline Size:63(W)×105.3(H) mm
Surface:Clear, Hard coating (3H)
Best View on:Symmetry
Display Colors:262K 35% NTSC
Lamp Type:7S1P WLED , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:4-wire Resistive Touch
Panel Weight:53.1g (Typ.)
Application:Handheld & PDA
Signal Interface:Parallel RGB (1 ch, 8-bit) , 39 pins FPC
Input Voltage:3.3/1.8V (Typ.)(VDD/VCCIO)
