Ortustech COM43H4M43KLC LCD

Specification

Model P/N:COM43H4M43KLC
Brand:Ortustech
Diagonal Size:4.3"
Resolution:480(RGB)×272, WQVGA 128PPI
Brightness:500 cd/m² (Typ.)
Contrast Ratio:400:1 (Typ.) (TM) 5.5:1 (Typ.) (RF)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:95.04(W)×53.856(H) mm
Bezel Opening:98.34(W)×57.21(H) mm
Response Time:40/60 (Max.)(Tr/Td)
Outline Size:105.5(W)×67.2(H) ×5.4(D) mm
Surface:Hard coating (3H)
Best View on:-
Display Colors:16.7M
Lamp Type:5S1P WLED , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:58.0g
Application:Industrial ，Automotive Display
Signal Interface:Parallel RGB (1 ch, 8-bit) , 45 pins FPC
Input Voltage:3.3V (Typ.)
