Ortustech COM35H3P45UTC LCD

Specification

Model P/N:COM35H3P45UTC
Brand:Ortustech
Diagonal Size:3.5"
Resolution:480(RGB)×640, VGA 228PPI
Contrast Ratio:800:1 (Typ.) (TM) 3:1 (Typ.) (RF)
Viewing Angle:80/80/80/80 (Min.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:53.28(W)×71.04(H) mm
Bezel Opening:57.5(W)×75.5(H) mm
Outline Dim:63.5(H)×85(V) mm
Treatment:Hard coating (3H)
Luminance:265 cd/m² (Typ.)
View Direction:Symmetry
Response Time:40/60 (Max.)(Tr/Td)
Operating Mode:VA, Normally Black, Transflective
Support Color:262K 50% NTSC
Light Source:WLED [6S1P] , 50K hours , W/O Driver
Weight:42.3g
Designed For:Handheld & PDA
Frame Rate:60Hz
Touch Panel:4-wire Resistive Touch
Interface Type:Parallel RGB (1 ch, 6-bit) , 39 pins FPC
Power Supply:3.0/1.8V (Typ.)(VDD/VCCIO)
