Ortustech COM33T3P55ZTC LCD

Specification

Model P/N:COM33T3P55ZTC
Brand:Ortustech
Diagonal Size:3.3"
Resolution:120(RGB)×320 104PPI
Contrast Ratio:300 : 1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Color Depth:262K 50% NTSC
Backlight:3S1P WLED , 50K hours , No Driver
Signal Type:Parallel RGB (1 ch, 6-bit) + SPI , FPC 39 pins
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:29.07(W)×77.52(H) mm
Bezel Opening:-
Treatment:Antiglare
Luminance:500 cd/m² (Typ.)
Response:40/60 (Max.)(Tr/Td) ms
Good View at:3 o'clock
Work Mode:TN, Normally White, Transmissive
Mass:-
Used for:Handheld & PDA
Refresh Rate:60Hz
Touchscreen:4-wire Resistive Touch
Voltage Supply:3.3V (Typ.)
Max Ratings:Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C
Outline (mm):38.5×90×6.55 (H×V×D)
