Ortustech COM33T3N46ZTC LCD

Specification

Model P/N:COM33T3N46ZTC
Brand:Ortustech
Diagonal Size:3.3"
Resolution:120(RGB)×320 104PPI
Brightness:500 cd/m² (Typ.)
Contrast Ratio:300:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:29.07(W)×77.52(H) mm
Bezel Opening:-
Response Time:40/60 (Max.)(Tr/Td)
Outline Size:38.5(W)×90(H) ×6.55(D) mm
Surface:Hard coating (3H)
Best View on:3 o'clock
Display Colors:262K
Lamp Type:3S1P WLED , 50K hours , Without Driver
Frequency:60Hz
Touch Screen:4-wire Resistive Touch
Panel Weight:37.0g
Application:Handheld & PDA
Signal Interface:Parallel RGB (1 ch, 6-bit) + SPI , 39 pins FPC
Input Voltage:3.3V (Typ.)
