BOE COG-VLSHT004-03 LCD

Specification

Model P/N:COG-VLSHT004-03
Brand:BOE
Diagonal Size:7.0"
Resolution:800(RGB)×480, WVGA 133PPI
Brightness:500 cd/m² (Typ.)
Contrast Ratio:900:1 (Typ.) (TM)
Viewing Angle:80/80/80/80 (Typ.)(CR≥10)
Panel Type:a-Si TFT-LCD, LCM
Pixel Format:RGB Vertical Stripe
Active Area:152.4(W)×91.44(H) mm
Bezel Opening:156.2(W)×94.54(H) mm
Response Time:30 (Typ.)(Tr+Td)
Outline Size:167.7(W)×109.45(H) ×19.8(D) mm
Surface:Antiglare
Best View on:Symmetry
Display Colors:16.7M 71% NTSC
Lamp Type:5S2P WLED , 30K hours , Without Driver
Frequency:60Hz
Touch Screen:Without
Panel Weight:0.23Kgs (Typ.)
Application:Industrial ，Automotive Display
Signal Interface:Parallel RGB (1 ch, 8-bit) + SPI , 55 pins FPC
Input Voltage:3.3V (Typ.)
